Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Litto
  • Model Number: LT 5000HD dual mppt solar inverter
  • Output Power: 5kW dual mppt solar inverter
  • Output Type: Single
  • Size: 355*405*170mm
  • Weight: 16.5KG
  • Input Voltage: 70-500V
  • Output Voltage: 110V/220V/230V/240Vac
  • Type: DC/AC Inverters
  • Output Frequency: 50Hz, 60Hz,;±5
  • Output Current: 20A
  • Max. efficiency: 98.5%
  • Euro-eta: 97.8%
  • MPPT efficiency: 99.9%
  • AC grid connection type: Single phase dual mppt solar inverter
  • Number of independent MPPT trackers: 2 MPPT
  • Strings per MPPT tracker: 2 strings dual mppt solar inverter
  • Noise emission(typical): 25dB(A)
  • Topology of dual mppt solar inverter: Transformerless
  • Environmental protection rating: IP65
  • Display: LCD, LED for dual mppt solar inverter

Packaging & Delivery

Packaging Details: Foam pack for each dual mppt solar inverter. Anti vibration. Export standard packing in cartons or on pallets.
Delivery Detail: 15-20 days after payment

98.5% high efficiency dual mppt solar power grid tie inverter 5kW connect to poly crystalline solar panels for home solar



ON-GRID DUAL MPPT SOLAR INVERTERS SYSTEM DIAGRAM





WIFI Monitoring of dual mppt solar inverter



For our Litto on grid dual mppt solar inverter, there's a portal that you can connect to in order to obtain data on the iPhone or Android. You just need to download the an APP on your mobile phone, then you can monitor the data as long as under WIFI environment.



The WIFI monitoring show below is our real display of our own solar power system 30kW, which is builded in our Factory LITTO NEW ENERGY CO.,LTD in Shenzhen city, Longhua District Fumin Road.



It's a grid connected dual mppt solar inverter. On one hand, we generate electricity by solar power for our own industrial load use. On the other hand, we've connected the grid, for extra power, we sell it to state with installing an electricity meter.







Product Description

Flexible

  • Two independent MPPT trackers for dual mppt solar inverter
  • Various power classes: from 1kW to 30kW dual mppt solar inverter
  • Available for both single phase and three phase dual mppt solar inverter

Efficient

  • Up to 1000 V DC input voltage range
  • 98.5% efficiency
  • 99.9% MTTP efficiency for dual mppt solar inverter

Secure Operation

  • Internal DC switch for added safety protection of dual mppt solar inverter
  • Transformerless design and easy installation
  • Compact design, no fan, low noise technique
  • Power factor continuously adjustable

Future-Proof

  • Comprehensive grid management functions
  • Ethernet-based communication, support USB, WIFI, GPRS
  • Standard ethernet RS485 output
  • 5 years standard warranty
  • IP65 compatible for dual mppt solar inverter
  • Film capacitor design, 25 years of design service life

Technical data



Our advantages of dual mppt solar inverter



Packaging & Shipping

  Foam pack for each dual mppt solar inverter. Anti vibration. Export standard packing in cartons or on pallets.

Exhibitions

Certificates

Company Information

XinChi Electric Co., Ltd is a group company. There are four branch companies subordinate to
it. Registered trademark is "suntree". Which is mainly produce electrical products, like ATS, PV combiner box, MCB, MCCB, etc.



LITTO NEW ENERGY CO.,LTD. is a subsidiary, with the registered trademark "Litto", which is mainly develop and research new energy products, like solar inverter. LITTO NEW ENERGY CO.,LTD owns the top engineers for both software and hardware in China, which is a leading inverter manufacturer with a wide range of inverter solutions including residential grid tie, off grid, commercial, solar power plant and solar monitoring systems.



Litto product line provides high-quality, reliable and technology-forward power inverter solutions. We offer you the right device for each application:for all module types, for grid-connection and feeding into stand-alone grids, for small house systems and commercial systems in the Megawatt range.

Quality &Standards:-Products are producted per ISO9001:2008, IEC60947, IEC60898,CB, SAA, TUV,CE,SONCAP,ROHS, Nemko, PCT,CCC etc.

Main markets:-Australia,New Zealand,Thailand, Euporean Countries&other worldwide markets.



Business strategies &Characristic:-Stability, expertise and technological innovation are the corner stones of our company’s business strategy.

We are trying to develop XinChi into a world-class Electrical manufactures.



Factory Profile
LITTO NEW ENERGY CO.,LTD.

Other Solar system products

We offer the whole solar system products. For grid connected solar inverter, we offer from solar panel, to pv combiner box/DC fuse/surge protective device/load isolator switch, to grid tie solar inverter, to energy meter, to home load MCB/MCCB, etc.



For off-grid solar inverter, we provide from solar panel, to controller, to batteries, to off-grid solar inverter.



For future, we're developing and researching the save energy type inverter, which we think it's a trendency for solar energy.



We have the most professional engineer wide in China, so we can give you most developed guide and advices whether for home solar system, or industrial solar system, etc.







FAQ

 1. How many years the quality guarantee of the on-grid solar inverter?

Normally 5 years quality guarantee, also can design 10 years quality guarantee if our customer require.



2. What type of the capacitor inside the inverter?

Film capacitor design.



3. How long does the service life for the on-grid solar inverter?

25 years of design service life.



4. Expect on-grid solar inverter, do you company also produce off-grid inverter?

Yes, we produce grid-connected solar inverter, off-grid inverter with batteries, and our engineers are endeavor to develop save energy inverter.



5. What's the after-sale service for your inverter?

We use WIFI, USB, GPRS, RS485 to monitor the working condition of the machine. Since every machine have a code, when something wrong with the machine, you just need to tell me your machine code, then we can monitor on internet and check out the real problems of the machine, then get back to you to solve it. No need to send it back to China.
