SHLX-PV Series 8 Strings PV Array Combiner Box DC Iron Material Solar Combiner Box

FOB Reference Price:Get Latest Price
$50.00 - $500.00 / Pieces | 1 Piece/Pieces (Min. Order)
Type:
combiner box
Lead Time:
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 15 Negotiable
Customization:
Customized packaging (Min. Order: 50000 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
suntree/oem
Model Number:
SHLX-PV
Protection Level:
IP65
Max current of each string:
0-20A
PV voltage range:
DC 1000V
Certificate:
IEC,ROHS,ISO,CE
color:
GREY
material:
iron
Output connection screw:
PG16
Mechanical life:
10years
Application:
Solar Power System
Brand:
Suntree
Supply Ability
Supply Ability:
200 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
standard packing
Port
ningbo/shanghai
Lead Time :
Quantity(Pieces) 1 - 5 >5
Est. Time(days) 15 To be negotiated
Video Description
Product Description

SHLX-PV8/1 PV combiner box bus synthetic DC input of 8 PV components to 1 output. Each channel is with a fuse. Output side is equipped with lightning protection and circuit breaker. It greatly simplify input wiring of DC power distribution cabinet and inverter. Realize lightning protecion, short circuit protection and grounding protection. PV combiner box divided into two types: intrlligent box and non-intelligent box . Intelligent PV combiner box is equipped with monitoring unit, then detect input current of each string, detect inside temperature, detect lightning protection status, detect circuit breaker status and summarize output voltage and so on.


Design and configuration strictly accordance with the "Technical specification for photovoltaic junction equipment" CGC/GF 037:2014.


Provide users with a safe, brief, beautiful and applicable photovoltaic system products.

The product adopts outdoor wall mounted type, which adapt to the harsh environment. In addition to the core components, the other can be customized by users requirements.

Product Parameters
Name
SHLX-PV8/1
System maximum dc voltage
1000
Maximum input current for each string
15A
Maximum input strings
8
Maximum output switch current
125A
Number of inverter MPPT
N
Number of Output strings
1
Category of test
‖ grade protection
Nominal discharge current
20ka
Maximum discharge current
40ka
Voltage protection level
3.8kv
Maximum continuous operating voltage Uc
1050A
Poles
3P
Structure characteristic
Plug-push module
Protection grade
IP65
Output switch
DC isolation switch(standard)/DC circuit
DC MC4/DC FUSE/DC Surge Protector
Standard
Monitoring module/Preventing diode
Optional
Installation method
Wall mounting type
Operating Temperature
-25℃--+55℃
Elevation of temperature
2km
Permissible relative humidity
0-95%, no condensation
Product Details Show
Our Advantages
♦High reliability
With DC FUSE
With DC Surge Protection Device
With DC circuit breaker or DC load isolation switch.

♦Strong adaptability
IP65 desigh,waterproof,anti dust and anti ularaviolet.
Strict test for high and low temperature,used widely/
The simple installation, the simplified system wiring, the convenient wiring.
The box body is made of cold rolled steel and other metal materials.

♦Flexible configuration
Used for single crystal silicon solar modules, polycrystalline silicon solar modules, thin film solar modules. Current rating of the photovoltaic fuse, cicuit breaker, load isolation switch is modified.
Recommend Products
Company Profile
FAQ
Q:  How can i trust you and your company ?
A: Suntree is a group company, we have 6 subcompanies. Have cooperation with LS, EKF the world-class companies. Our company over 500 employees, products pass CE,IEC,TUV,SAA, RCM, ROHS certificates.

Q:How long is your products warranty ?
A: The warranty period of our products is 2 Years.

Q:How about inspection?
A: We have the whole inspection system from raw material to end products include Transient test, delay test,mechanical life test and so on.

Q:What is the service offered by company?
A: We have the professional enginer team which can design and develop the mold to arrive different customer requirement.
We also have the sales team to offer good service from pre-sale to after-sale.
